RADIO TÉLÉVISION

Prix HT: 1250, 00 €  Prix TVA: 1495,00 €

FM BROADCAST FM RECEIVER RTX - 1
Frequency range from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation
Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation

Synthesis step 10kHz

Modulation distortion  @  1 Khz / 100% deviation mono <0,01  0.05% typ stéréo,1ch < 0.02% typical

S/N ratio, mono 30÷20000Hz >76 dB, 86 typical CCIR >75 dB, 81 typical - S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CIR >68 dB, 72 typical

Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 !s selectable

Rated RF output power 30W - Transmitter tuning steps 10/100 KHz

Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious)

RF output connector N  - Power supply Single phase 230 VAc +10 -20% Three phase N.A. - Total consumption 85W -
Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing -
Dimensions (WxHxD) 483x88x375 mm  - Weight 5kg

FM BROADCAST FM RECEIVER RAG FM MPX
FREQUENCY RANGE 87.5 ÷ 108MHz

CHANNEL SETTING By two pushbuttons - with password - TUNING STEP 10KHz -ANTENNA INPUT LEVEL from - 80dBm to 0dBm with no overload - ANTENNA CONNECTOR N-F 50 OHM - IMAGE REJECTION > 80dB

IF REJECTION > 90dB - FREQUENCY METER High visibility LCD Digital Display

DEVIATION INDICATION High visibility LCD Digital Display - CARRIER LEVEL METERING Showing dBμV

FREQUENCY ACCURACY ｱ 2,5 ppm - IF BANDWIDTH 280 KHz ｱ 5%

SIGNAL to NOISE RATIO 74dB @ 400Hz with 50μS - HARMONIC DISTORTION < 0.2%

FREQUENCY RESPONSE ｱ 0.05dB 30Hz to 60KHz - STEREO CROSSTALK 40dB 100Hz ・10KHz (typ. 45dB @1KHz)

MPX OUTPUT CONNECTOR BNC-F 2,2V PeP 30 OHM - MUTING Adjustable from -80dBm to -30dBm

MONITORING With 6,3mm Jack-earphone connector level adjusting

POWERING AC 110÷ 240V - DIMENSIONS 1HE rack 19" 38cm (D) - WEIGHT 3,2 Kg

FM BROADCAST FM RECEIVER RTX -2
Frequency range from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation
Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation Synthesis step 10kHz

Modulation distortion  @  1 Khz / 100% deviation mono <0,01  0.05% typ stéréo,1ch < 0.02% typical

S/N ratio, mono 30÷20000Hz >76 dB, 86 typical CCIR >75 dB, 81 typical - S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CIR >68 dB, 72 typical

Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 !s selectable

Rated RF output power 30W - Transmitter tuning steps 10/100 KHz

Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious)

RF output connector N  - Power supply Single phase 230 VAc +10 -20% Three phase N.A. - Total consumption 85W -
Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing - Dimensions (WxHxD) 483x88x375 mm  - Weight 5kg

Prix HT: 1490,00 €  Prix TVA: 1782,04 €

Survolez l’image pour l’agrandir

Survolez l’image pour l’agrandir

En savoir plus

Prix HT: 1690,00 €  Prix TVA: 2021,24 €
