Bienvenue sur FMA BROADCAST FM La radio fm et la télévision c'est nous! Vous trouverez tout le matériel pour créer votre propre radio fm télévision locale, équiper votre studio radio fm et télévision, Installation de votre station radio & Tv de A à Z. Radio Afrique, Package complet radio fm "clef en main" nos produits: Kit Station FM mobile de 100W, Kit Station Radio 100W, Kit Station radio 250W, Kit Station radio Fm 500W, Kit Station radio Fm 1000W, Kit Station radio 1500W, Kit Station radio 2000W,, autres systèmes disponibles, sonorisation, éclairage, discothèque, clubs, installation, montage, maintenance, étude et déplacement sur place de vos projets partout dans le monde, vente de matériel : émetteurs, amplificateurs, pylône, antenne fm, antenne d’émission télévision, station de diffusion de programmation de radio fm, studio de production, devis sur demande, radio Afrique... RADIO AFRIQUE BROADCAST FM équipements & installation partout dans le monde. "FM Association des radiodiffuseurs communautaires d'Afrique"

Prix HT: 2950, 00 €  Prix TVA: 3528, 20 €

AMPLIFICATEUR RFB1000W

Frequency range from 87,5 to 108 MHz

FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation - Auxiliary input channel level

SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation - RDS from -24 to -8 dBm @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical - CCIR >75 dB, 79 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 500W, 1000W, 1500W - Transmitter tuning steps 10/100 KHz

Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious)

RF output connector 7/16 - Power supply Single phase 230 VAc ± 15% - Three phase N.A. - Total consumption at rated RF power <830W (EXC500GT), <2400W (EXC1500GT) - Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating)

Relative humidity up to 95% not condensing

Dimensions (WxHxD) 483x88x585 mm - Weight 12kg

Amplificateurs radio fm

AMPLIFICATEUR 600W
Frequency Range:  76,0 to 98MHz and 87,5 to 108,1MHz

Harmonic and Spurious Attenuation:  >85dBc

Output Power:  620W +/- 5% variation across the band - RF Output Impedance:  50 Ohms - RF Output connector:  N Female

Power Supply: AC input:  220V 47-63Hz +/- 20% Variation - DC Input:  Not available in this version

AC Surge protection:  3 Varistor 285V, gas discharger and fuse - Power Supply Efficiency:  85% or better in 220V AC

Switching frequency:  100kHz - Power Consumption:  Approximately 400W from AC - AC Input Connector:  IEC socket connector

CPU and Display features: CPU:  PIC Processor, microcontrolled with Sinteck SMT6 Software V.1.0 - Memory:  Nonvolatile, retention > 40 years

Full micro-controlled Protections:  VDC protection, ADC protection, TEMP excedeed, VSWR excedeed - Panel Keys Control:  Selection of measured patterns, RF power Adjust - LCD Display:  16 colums, 2 lines, green back light - RF Input: Input Impedance:  50 Ohms - Input Connector:  N Female (UHF under request) - Input RF power (normal operating):  6 to 15W - Input RF power (maximum):  25W

General features: Ambient temperature range:  0 to +45 - Degrees Celsius Maximum humidity:  95% at +45ºC without condensation
Dimensions:  483mm (6”) wide, 88,90mm (2 RU) high, 355mm (14”) deep - Weight:  14,5kgs net weight

AMPLIFICATEUR RFB 1500W

Frequency range from 87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation - Auxiliary input channel level

SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation - RDS from -24 to -8 dBm @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical - CCIR >75 dB, 79 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 500W, 1000W, 1500W - Transmitter tuning steps 10/100 KHz

Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious)

RF output connector 7/16 - Power supply Single phase 230 VAc ± 15% - Three phase N.A. - Total consumption at rated RF power <830W (EXC500GT), <2400W (EXC1500GT) - Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating)

Relative humidity up to 95% not condensing - Dimensions (WxHxD) 483x88x585 mm - Weight 12kg


AMPLIFICATEUR RFB 2000W

Frequency range from 87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation - Auxiliary input channel level SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation - RDS from -24 to -8 dBm @ 2 KHz deviation -Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB

Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 2000W, 2500W, 3000W, 4000W -Transmitter tuning steps 10/100 Khz - Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) - RF output connector 7/8" - Power supply Single phase 230 Vac ± 15% Three phase 230 or 400 Vac ± 15% with neutral line - Total consumption at rated

RF power <3900W (EXC2500GT), <6400W (EXC4000GT) - Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) - Relative humidity up to 95% not condensing - Dimensions (WxHxD) 483x177x650 mm  - Weight 30kg

Prix HT: 5742,00 €  Prix TVA: 6867,43 €

Prix HT: 7493,20 €  Prix TVA: 8937,95 €

Prix HT: 10655,2 € Prix TVA: 12743, 20 €

AMPLIFICATEUR RFB 2500W

Frequency range from 87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation - Auxiliary input channel level SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation - RDS from -24 to -8 dBm @ 2 KHz deviation -Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB

Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 2000W, 2500W, 3000W, 4000W -Transmitter tuning steps 10/100 Khz - Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) - RF output connector 7/8" - Power supply Single phase 230 Vac ± 15% Three phase 230 or 400 Vac ± 15% with neutral line - Total consumption at rated

RF power <3900W (EXC2500GT), <6400W (EXC4000GT) - Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) - Relative humidity up to 95% not condensing - Dimensions (WxHxD) 483x177x650 mm  - Weight 30kg

Prix HT: 11519,8 €  Prix TVA: 13777,68 €

AMPLIFICATEUR RFB 3000W
Frequency range
from 87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation - Auxiliary input channel level SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation - RDS from -24 to -8 dBm @ 2 KHz deviation -Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB

Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 2000W, 2500W, 3000W, 4000W -Transmitter tuning steps 10/100 Khz - Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) - RF output connector 7/8" - Power supply Single phase 230 Vac ± 15% Three phase 230 or 400 Vac ± 15% with neutral line - Total consumption at rated

RF power <3900W (EXC2500GT), <6400W (EXC4000GT) - Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) - Relative humidity up to 95% not condensing - Dimensions (WxHxD) 483x177x650 mm  - Weight 30kg

Prix HT: 22400,8 €  Prix TVA: 26791,36 €

AMPLIFICATEUR RFB 4000W
Frequency range
from 87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation - Auxiliary input channel level SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation - RDS from -24 to -8 dBm @ 2 KHz deviation -Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB

Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 2000W, 2500W, 3000W, 4000W -Transmitter tuning steps 10/100 Khz - Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) - RF output connector 7/8" - Power supply Single phase 230 Vac ± 15% Three phase 230 or 400 Vac ± 15% with neutral line - Total consumption at rated

RF power <3900W (EXC2500GT), <6400W (EXC4000GT) - Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) - Relative humidity up to 95% not condensing - Dimensions (WxHxD) 483x177x650 mm  - Weight 30kg

Prix HT: 26338,2 €  Prix TVA: 31500,49 €

AMPLIFICATEUR RFB 5000W
Frequency range from 87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation

Auxiliary input channel level SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation RDS from -24 to -8 dBm @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical

Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable

Rated RF output power 5000W - Transmitter tuning steps 10/100 Khz - Output power ALC stability ±3%

Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) - RF output connector 7/8" - Power supply Single phase 230 Vac ± 15% Three phase 230 or 400 Vac ± 15% with neutral line - Total consumption at rated RF power 7800W - Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) - Relative humidity up to 95% not condensing

Dimensions (WxHxD) 483x266x670 mm  -Weight 44kg

Prix HT: 31086,8 € Prix TVA:37179,81 €

BROADCAST 2000W COMPACT AMPLIFIER ASM2K
FREQUENCY RANGE: .
87.5 ÷ 108 MHz (76 88MHz on request) -MODULATION:. FM
RF OUT CONNECTOR: .
N FOR - RF INP CONNECTOR: . Type 7/8 - 7/16 7/16 for RF OUTPUT - IMPEDANCE: . 50 Ohm - INPUT POWER:. 20-25W nor:35w - POWER OUTPUT: .2000W - MONITOR OUTPUT : 54 dB, tip - ATTENUATION HARMONICS: <75 dB -
IN OUT IMPEDANCE:  50 Ohm

INPUT CONNECTOR: N  -  OUTPUT CONNECTOR :  7/8 - 7/16 on demand - OUTPUT MONITOR RF: BNC

MONOPHASE ELECTRICAL SUPPLY: 190  264 Vac 50/60 Hz

hreephase electrical supply 400 Vac (230 on demand)

Max current on aux terminal 1 A @ 230 Vac, no fuse

POWR FACTOR: Telemetry optional all models

DIMENSIONS: cm. (W x H x L) 42 x 17,5 x 55-  WEIGHT : 22 Kg

D

Temperature di funzionamento

0°  35° C raccom. -10°  45° C max

Prix HT:  46500 € Prix TVA: 55614,00 €

BROADCAST 5000W COMPACT AMPLIFIER ASM5K
FREQUENCY RANGE: .
87.5 ÷ 108 MHz (76 88MHz on request) -MODULATION:. FM
RF OUT CONNECTOR: .
N FOR - RF INP CONNECTOR: . type 7/16 for RF OUTPUT - IMPEDANCE: . 50 Ohm - INPUT POWER:. 40-60W setting from 100 W to 1.2 KW - POWER OUTPUT: .0 ÷ 5.000 Watts ALC - self redundancy (if one of 4 x 1250W sub-amplifiers breaks, - OVERAL EFFECIENCY: . Better Than 70% - HARMONIC & SPURIOUS: . <-75dBc- AM residual as -75 dB - RF PROBE: . -60 dBC via BNC connector

POWER SUPPLY: . Switch Mode (Double conversion voltage mains direct)(48 V / 20 A) - TYPE MOS- FET AMPLIFIER: . (8 x BLF 578)

DISPLAY: . Forward power - Reflected Power - DC Supply Voltage -  Power Supply Temperature - Power Amplifier Voltage

PROTECTIONS: POWER SUPPLY: . 180 - 240V AC  +/-20% - RF AMLIFIER: . RF module over-temperature 70deg C - derates to 1000W at 80deg C

VSWR protection: . (an antenna SWR value higher than 100 W send the equipment in protection, lowering automatically the output power)

COOLING: . 4 Blowers 24V DC 80 x 80 - DIMENSIONS: . Rack (4U) 18H x 48W x 67D (CM) - WEIGHT: . 35 Kg

Prix HT:  on request  Prix TVA:
