Bienvenue sur FMA BROADCAST FM La radio fm et la télévision c'est nous! Vous trouverez tout le matériel pour créer votre propre radio fm télévision locale, équiper votre studio radio fm et télévision, Installation de votre station radio & Tv de A à Z. Radio Afrique, Package complet radio fm "clef en main" nos produits: Kit Station FM mobile de 100W, Kit Station Radio 100W, Kit Station radio 250W, Kit Station radio Fm 500W, Kit Station radio Fm 1000W, Kit Station radio 1500W, Kit Station radio 2000W,, autres systèmes disponibles, sonorisation, éclairage, discothèque, clubs, installation, montage, maintenance, étude et déplacement sur place de vos projets partout dans le monde, vente de matériel : émetteurs, amplificateurs, pylône, antenne fm, antenne d’émission télévision, station de diffusion de programmation de radio fm, studio de production, devis sur demande, radio Afrique... RADIO AFRIQUE BROADCAST FM équipements & installation partout dans le monde. "FM Association des radiodiffuseurs communautaires d'Afrique"

Prix HT: 1515, 40 €  Prix TVA: 1818, 48 €

EXC 100 GT TRANSMITTER

Frequency range from 87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation

Auxiliary input channel level SCA from -12,5 to +3,5 dBm  @ 7,5 KHz deviation RDS from -24 to -8 dBm  @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 86 typical  CCIR >75 dB, 81 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical

Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 100W or 300W - Transmitter tuning steps 10/100 Khz Output power ALC stability ±3%

Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious)

RF output connector N - Power supply Single phase 100 ÷ 250 Vac Three phase N.A. Total consumption at rated RF power <220W (EXC100GT), <600W (EXC300GT) Operative temperature range suggested from 0 to 35 °C

extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing
Dimensions (WxHxD) 483x88x395 m  - Weight 7kg

Emetteurs radio fm 15w / 5Kw

EXC 30 GT EXCITER
Frequency range from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation

Auxiliary input channel level SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation - RDS from -24 to -8 dBm @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical

S/N ratio, mono 30÷20000Hz >76 dB, 86 typical CCIR >75 dB, 81 typical - S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CIR >68 dB, 72 typical

Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 !s selectable

Rated RF output power 30W - Transmitter tuning steps 10/100 KHz

Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious)

RF output connector N  - Power supply Single phase 230 VAc +10 -20% Three phase N.A. - Total consumption 85W -
Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing -
Dimensions (WxHxD) 483x88x375 mm  - Weight 5kg




En savoir plus

EXC 300 GT TRANSMITTER

Frequency range from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation

Auxiliary input channel level SCA from -12,5 to +3,5 dBm  @ 7,5 KHz deviation RDS from -24 to -8 dBm  @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 86 typical  CCIR >75 dB, 81 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical

Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 100W or 300W - Transmitter tuning steps 10/100 Khz Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) - RF output connector N - Power supply Single phase 100 ÷ 250 Vac Three phase N.A. -Total consumption at rated RF power <220W (EXC100GT), <600W (EXC300GT) Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing - Dimensions (WxHxD) 483x88x395 m  - Weight 7kg

EXC 500 GT TRANSMITTER
Frequency range
from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm  75 KHz deviation

Auxiliary input channel level SCA from -12,5 to +3,5 dBm  7,5 KHz deviation RDS from -24 to -8 dBm  2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical  CCIR >75 dB, 79 typical - S/N ratio, stereo30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable Rated RF output power 500W, 1000W, 1500W - Transmitter tuning steps 10/100 Khz - Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) -RF output connector 7/16 - Power supply Single phase 230 VAc ± 15% Three phase N.A. Total consumption at rated RF power <830W (EXC500GT), <2400W (EXC1500GT) Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing

Dimensions (WxHxD) 483x88x585 mm  Weight 12kg


E-mail: afwaymusic@yahoo.fr?subject=FMA est fournisseur d’équipement radio fm&body=Bonjour, FMA BROADCAST FM

Prix HT: 1949, 40 €  Prix TVA: 2339, 28 €

Prix HT: 2316, 00 €  Prix TVA: 2879, 20 €

Prix HT: 3926, 00 € Prix TVA: 4711, 20 €

EXC 1000 GT EXCITER
Frequency range from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm  75 KHz deviation

Auxiliary input channel level SCA from -12,5 to +3,5 dBm  7,5 KHz deviation RDS from -24 to -8 dBm  2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical  CCIR >75 dB, 79 typical - S/N ratio, stereo30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable Rated RF output power 500W, 1000W, 1500W - Transmitter tuning steps 10/100 Khz - Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) -RF output connector 7/16 - Power supply Single phase 230 VAc ± 15% Three phase N.A. Total consumption at rated RF power <830W (EXC500GT), <2400W (EXC1500GT) Operative trmperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing

Dimensions (WxHxD) 483x88x585 mm  Weight 12kg

Prix HT: 4912, 00 €  Prix TVA: 5894, 40 €

EXC 1500 GT TRANSMITTER

Frequency range from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation Auxiliary input channel level SCA from -12,5 to +3,5 EXC 1500 GT dBm @ 7,5 KHz deviation RDS from -24 to -8 dBm @ 2 KHz deviation Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical - S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable Rated RF output power 500W, 1000W, 1500W -Transmitter tuning steps 10/100 Khz - Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) - RF output connector 7/16 - Power supply Single phase 230 VAc ± 15% Three phase N.A. - Total consumption at rated RF power <830W (EXC500GT), <2400W (EXC1500GT) Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating)Relative humidity up to 95% not condensing - Dimensions (WxHxD) 483x88x585 mm - Weight 12kg

Prix HT: 6572, 00 €  Prix TVA: 7886, 40 €

EXC 2000 GT TRANSMITTER
Frequency range from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation

Auxiliary input channel level SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation RDS from -24 to -8 dBm @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical - S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 2000W, 2500W, 3000W, 4000W - Transmitter tuning steps 10/100 KHz

Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious)

RF output connector 7/8" - Power supply Single phase 230 Vac ± 15% Three phase 230 or 400 Vac ± 15% with neutral line

Total consumption at rated RF power <3900W (EXC2500GT), <6400W (EXC4000GT) - Operative temperature range suggested from 0 to 35 °C

extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing - Dimensions (WxHxD) 483x177x650 mm  Weight 30kg

Prix HT: 8972, 00 €  Prix TVA: 10766, 40 €

EXC 2500 GT

Frequency range from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation Auxiliary input channel level

SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation RDS from -24 to -8 dBm @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical - S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical - S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 2000W, 2500W, 3000W, 4000W - Transmitter tuning steps 10/100 KHz

Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious)

RF output connector 7/8"- Power supply Single phase 230 Vac ± 15% Three phase 230 or 400 Vac ± 15% with neutral line

Total consumption at rated RF power <3900W (EXC2500GT), <6400W (EXC4000GT)

Operative temperature rangesuggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing Dimensions (WxHxD) 483x177x650 mm  - Weight 30kg idem technique pour le EXC 3000 GT TRANSMITTER

Prix HT: 11852, 00 € Prix TVA: 14222, 40 €

EXC 4000 GT TRANSMITTER

Frequency range from  87,5 to 108 Mhz -FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation

Auxiliary input channel level SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation RDS from -24 to -8 dBm @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical S/N ratio, mono30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical -Audio channels frequency response 30÷15000 Hz ±0.1 dB - Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 2000W, 2500W, 3000W, 4000W Transmitter tuning steps 10/100 Khz - Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) - RF output connector 7/8" - Power supply Single phase 230 Vac ± 15% Three phase 230 or 400 Vac ± 15% with neutral line Total consumption at rated RF power <3900W (EXC2500GT), <6400W (EXC4000GT) - Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing Dimensions (WxHxD) 483x177x650 mm - Weight 30kg

Prix HT:  15952, 00 € Prix TVA: 19142, 40 €

EXC 5000 GT TRANSMITTER

Frequency range from  87,5 to 108 Mhz - FM modulation 75 KHz peak deviation (adjustable)

Audio and Mpx input level from -3,5 to +12,5 dBm @ 75 KHz deviation

Auxiliary input channel level SCA from -12,5 to +3,5 dBm @ 7,5 KHz deviation RDS from -24 to -8 dBm @ 2 KHz deviation

Modulation distortion 75 KHz deviation <0.05%, 0.02% typical S/N ratio, mono 30÷20000Hz >76 dB, 80 typical CCIR >75 dB, 79 typical

S/N ratio, stereo 30÷20000Hz >72 dB, 77 typical CCIR >68 dB, 72 typical - Audio channels frequency response 30÷15000 Hz ±0.1 dB

Pre-emphasis time constant 25/50/75 μs selectable - Rated RF output power 5000W Transmitter tuning steps 10/100 Khz Output power ALC stability ±3% - Harmonic and spurious emissions <70dB (harmonic), <80 dBc (spurious) - RF output connector 7/8" Power supply

Single phase 230 Vac ± 15% Three phase 230 or 400 Vac ± 15% with neutral line Total consumption at rated RF power 7800W Operative temperature range suggested from 0 to 35 °C extreme from -10 to +50 °C max (with derating) Relative humidity up to 95% not condensing  Dimennsions (WxHxD)  (483x266x670 mm  - Weight 44kg


Prix HT:  18652, 00 €  Prix TVA: 22382, 40 €

TRANSMITTER mod Esva 20W
FREQUENCY RANGE: . 87.5 a 108 Mhz - MODULATION:  FM

EMISSION CLASS: . F3E - VCO TUNING:.25 Mhz - FREQUENCY STABILITY:. 2.5 ppm - SYNTHESIZER STEP: . 10KHz

POWER OUTPUT: . 0 a 20 Watts ( 0 ￷ 50 Watts - special) - SPURIOUS EMISSION:. < - 80 dB or better

HARMONIC EMISSION: .< - 65 dB - STEREO SEPARATION: . > 55 dB @ 1KHz - DISTORSION: . < 0.1 % (TYP. 0.06%) @ 1KHz - BASE BAND: . 30 Hz ￷ 60 KHz within 0.15 dB - UNWEIGHTED S/N RATIO: . > 80 dB (30Hz ￷ 15KHz 50 S RMS) - ASYNCRONOUS AM S/N Ratio: . > 70 dB Ref. 100% AM 400Hz - SYNCRONOUS AM S/N Ratio: .. > 65 dB with FM @ 75KHz @400Hz - PRE-ENPHASIS: . 50 OR 75 μS int. selectable

RF OUT CONNECTOR: . N-F 50 Ohm - MPX INPUT CONNECTOR: . BNC-F - MPX INPUT IMPEDANCE: . 2 Kohm - SCA INPUT CONNECTOR: . 3 BNC-F

COOLING: . Forced air by two brushless fans - OP.TEMPERATURE RANGE: . - 10 ￷ +45 ￷

MAXIMUM UMIDITY: . 90 % - AC SUPPLY: .. 100 ￷ 240 VAC - 47 ￷ 63 Hz - DIMENSION: . 1 unit rack 19", 405mm depth - WEIGHT: . 5 Kg

Prix HT:  950, 00 € Prix TVA: 1140, 00 €

FM 100W BROADCAST TRANSMITTER mod.ESVA 100
FREQUENCY RANGE: . 87.5a108 MHz (76￷88MHz on request) - MODULATION: . FM

EMISSION CLASS: . F3E -VCO TUNING: . 25 Mhz - FREQUENCY STABILITY: . ᄆ 2.5 ppm - SYNTHESIZER STEP: . 10KHz

POWER OUTPUT: . 0 ￷ 130 Watts - SPURIOUS EMISSION: . < - 80 dB or better - HARMONIC EMISSION: . < - 65 dB - STEREO SEPARATION: . > 55 dB @ 1KHz - DISTORSION: . < 0.1 % (TYP. 0.06%) @ 1KHz - BASE BAND: . 30 Hz ￷ 60 KHz within 0.15 dB - UNWEIGHTED S/N RATIO: . >80 dB (30Hz ￷ 15KHz 50 S RMS) - ASYNCRONOUS AM S/N Ratio: . > 70 dB Ref. 100% AM 400Hz - SYNCRONOUS AM S/N Ratio: . > 65 dB with FM @ 75KHz @400Hz - PRE-ENPHASIS: . 50 OR 75 μS int. Selectable - RF OUT CONNECTOR: . N-F 50 Ohm - MPX INPUT CONNECTOR: . BNC-F - MPX INPUT IMPEDANCE: . 2 Kohm - SCA INPUT CONNECTOR:. 3 BNC-F - COOLING: Forced by two brushless fans - OP.TEMPERATURE RANGE: .- 10 ￷ +45 - MAXIMUM UMIDITY: . 90 % - AC. 100 ￷ 240 VAC - 47 ￷ 63 Hz - DIMENSION: . 2 unit rack 19", 405mm depth - WEIGHT: . 10 Kg

Prix HT:  1500, 00€ Prix TVA: 1800, 00 €

Prix HT:  1800, 00  € Prix TVA: 2160, 00 €

Survolez l’image pour l’agrandir

Survolez l’image pour l’agrandir

Broadcast FM transmitter mod. ESVA250
FREQUENCY RANGE: .
87.5a108 MHz (76￷88 MHz on request) -MODULATION: . FM

EMISSION CLASS: . F3E - TUNING: . 25 Mhz -FREQUENCY STABILITY: . ア 2.5 ppm - SYNTHESIZER STEP: . 10KHz
POWER OUTPUT: . 0 ￷ 250 W (max.270W) - SPURIOUS MISSION: . < - 80 dB or better - HARMONIC EMISSION: . < - 65 dB - STEREO SEPARATION: . > 55 dB @ 1KHz - DISTORSION: .< 0.1 % (TYP. 0.06%) @ 1KHz - BASE BAND: . 30 Hz ￷ 60 KHz within 0.15 dB - UNWEIGHTED S/N RATIO: . > 80 dB (30Hz ￷ 15KHz 50 uS RMS) - ASYNCRONOUS AM S/N Ratio: . > 70 dB Ref. 100% AM 400Hz - SYNCRONOUS AM S/N Ratio: .  > 65 dB with FM @ 75KHz @400Hz - PRE-ENPHASIS: .50 OR 75 μS int. Selectable - RF OUT CONNECTOR: . N-F 50 Ohm - MPX INPUT CONNECTOR: . BNC-F - MPX INPUT IMPEDANCE: . 2 Kohm - SCA INPUT CONNECTOR: . 3 BNC-F - COOLING: . Forced air by brushless fan - OP.TEMPERATURE RANGE: . - 10 ￷ +45 C

MAXIMUM UMIDITY: . 90 % - AC SUPPLY: . 100 ￷ 240 VAC - 47 ￷ 63 Hz - DIMENSION: rack 19", 435mm depth - WEIGHT: . 12Kg

BROADCAST 500W COMPACT TRANSMITTER
FREQUENCY RANGE: .
87.5 a ÷ 108 MHz (76 88MHz on request) - TYPE: . SOLID STATE MOS-FET-WIDE BAND - MODULATION:. FM

EMISSION CLASS: . F3E - VCO TUNING: . 25 Mhz - FREQUENCY STABILITY: . 2,5 ppm - SYNTHESIZER STEP: . 100KHz (10KHz on request)

POWER OUTPUT: . 0 ÷ 500 Watts - SPURIOUS EMISSION: . < - 80 dB or better - HARMONIC EMISSION: . < - 60 dB - STEREO SEPARATION: . > 55 dB @ 1KHz - DISTORSION: . < 0.1 % (TYP. 0.06%) @ 1KHz - BASE BAND: . 30 Hz ÷ 60 KHz within 0.15 dB - UNWEIGHTED S/N RATIO:. > 80 dB (30Hz 15KHz 50 S RMS) - ASYNCRONOUS AM S/N Ratio: . > 65 dB Ref. 100% AM 400Hz -SYNCRONOUS AM S/N Ratio: . > 65 dB with FM @ 75KHz @400Hz - PRE-ENPHASIS: . 50 OR 75 ìS int. Selectable - RF OUT CONNECTOR: . N female - MPX INPUT CONNECTOR: . BNC-F

MPX INPUT IMPEDANCE: . 2 Kohm - SCA INPUT CONNECTOR: . 3 BNC-F - PROTECTIONS: . OVERLOAD, - VSWR in a fold-back reducing power

TEMPERATURE COOLING: . Forced Air - OP.TEMPERATURE RANGE: . 0 ÷ +50 °C - MAXIMUM UMIDITY: . 90 % - AC SUPPLY: . 100 ÷ 240 VAC - 47 ÷ 63 Hz - DIMENSION: . 3 unit rack 19", 530mm depth - WEIGHT: . 15 Kg


Prix HT:  3200, 00  € Prix TVA: 3840, 00 €

BROADCAST 1000W COMPACT TRANSMITTER
FREQUENCY RANGE: .
87.5 a ÷ 108 MHz (76 88MHz on request) - TYPE: . SOLID STATE MOS-FET-WIDE BAND - MODULATION:. FM

EMISSION CLASS: . F3E - VCO TUNING: . 25 Mhz - FREQUENCY STABILITY: . 2,5 ppm - SYNTHESIZER STEP: . 100KHz (10KHz on request)

POWER OUTPUT: . 0 ÷ 1000 Watts - SPURIOUS EMISSION: . < - 80 dB or better - HARMONIC EMISSION: . < - 60 dB - STEREO SEPARATION: . > 55 dB @ 1KHz - DISTORSION: . < 0.1 % (TYP. 0.06%) @ 1KHz - BASE BAND: . 30 Hz ÷ 60 KHz within 0.15 dB - UNWEIGHTED S/N RATIO:. > 80 dB (30Hz 15KHz 50 S RMS) - ASYNCRONOUS AM S/N Ratio: . > 65 dB Ref. 100% AM 400Hz -SYNCRONOUS AM S/N Ratio: . > 65 dB with FM @ 75KHz @400Hz - PRE-ENPHASIS: . 50 OR 75 ìS int. Selectable - RF OUT CONNECTOR: . N female - MPX INPUT CONNECTOR: . BNC-F

MPX INPUT IMPEDANCE: . 2 Kohm - SCA INPUT CONNECTOR: . 3 BNC-F - PROTECTIONS: . OVERLOAD, - VSWR in a fold-back reducing power

TEMPERATURE COOLING: . Forced Air - OP.TEMPERATURE RANGE: . 0 ÷ +50 °C - MAXIMUM UMIDITY: . 90 % - AC SUPPLY: . 100 ÷ 240 VAC - 47 ÷ 63 Hz - DIMENSION: . 3 unit rack 19", 530mm depth - WEIGHT: . 18 Kg

Prix HT:  4250, 00 € Prix TVA: 5100, 00 €

Survolez l’image pour l’agrandir

Survolez l’image pour l’agrandir

Survolez l’image pour l’agrandir

Survolez l’image pour l’agrandir

BROADCAST 5000W COMPACT TRANSMITTER ASM5K
FREQUENCY RANGE: .
87.5 ÷ 108 MHz (76 88MHz on request) -MODULATION:. FM
RF OUT CONNECTOR: .
N FOR - RF INP CONNECTOR: . type 7/16 for RF OUTPUT - IMPEDANCE: . 50 Ohm - INPUT POWER:. 40-60W setting from 100 W to 1.2 KW - POWER OUTPUT: .0 ÷ 5.000 Watts ALC - self redundancy (if one of 4 x 1250W sub-amplifiers breaks, - OVERAL EFFECIENCY: . Better Than 70% - HARMONIC & SPURIOUS: . <-75dBc- AM residual as -75 dB - RF PROBE: . -60 dBC via BNC connector

POWER SUPPLY: . Switch Mode (Double conversion voltage mains direct)(48 V / 20 A) - TYPE MOS- FET AMPLIFIER: . (8 x BLF 578)

DISPLAY: . Forward power - Reflected Power - DC Supply Voltage -  Power Supply Temperature - Power Amplifier Voltage

PROTECTIONS: POWER SUPPLY: . 180 - 240V AC  +/-20% - RF AMLIFIER: . RF module over-temperature 70deg C - derates to 1000W at 80deg C

VSWR protection: . (an antenna SWR value higher than 100 W send the equipment in protection, lowering automatically the output power)

COOLING: . 4 Blowers 24V DC 80 x 80 - DIMENSIONS: . Rack (4U) 18H x 48W x 67D (CM) - WEIGHT: . 35 Kg

Prix HT:  12500, 00  € Prix TVA: 15000, 00 €

BROADCAST EX 15W  FM EXITER
Frequency Range: .
87.5 ÷ 108 MHz  -Modulation:. FM
Type de modulation: . F3 - Harmonic and spurious Attenuation: >80dBc - Residual AM modulation (Assyncr.) Approximately 0,05% (55dB)

Residual AM modulation (Syncr.) Approximately 0,1% (65dB) - Intermodulation Distortion: <0,05% @ 1kHz - Frequency Response Capability: 20Hz to 200kHz - AC Input: Universal Full-Range to 265VAC 47 to 63Hz - AC Surge Protection: 3 Varistor 285V, gas discharger and fuse

Power Supply Efficiency: 85% or better in 220V AC - Switching Frequency: 100kHz - Audio Inputs Left&Right: Input Connectors: XLR Female - Internal Jumper selection for: 50 or 75us stereo pre-emphasis - Input Impedance: 600 Ohms umbalanced - Frequency Response: 20Hz to 15kHz (THD+N < 0,1%) - Input Level: 0dB for 75KHz carrier deviation - Stereo Separation: Better than 45dB @ 1kHz - Pilot Tone Frequency/Stability: 19kHz +/- 1Hz - MPX Input: Input Impedance: 10k Ohms Unbalanced BNC Connector - Frequency Response: 20Hz to 200KHz +/- 1dB for 75kHz deviation - Maximum humidity:  95% at +45ºC without condensation - *Specification subject to change without notice - Dimensions: 483mm (6”) wide, 44,45mm (1,5”) high, 150mm (4”) deep - Weight: 1,5kgs

Prix HT:  870, 00  € Prix TVA: 1044, 00 €

BROADCAST EX 30W  FM EXITER
Frequency Range: .
87.5 ÷ 108 MHz  -Modulation:. FM
Type de modulation: . F3 - Harmonic and Spurious Attenuation:  >80dBc - Residual AM modulation (Assyncr.)  Approximately 0,05% (55dB) - Residual AM modulation (Syncr.)  Approximately 0,1% (65dB) - Intermodulation Distortion:  <0,05% @ 1kHz -Frequency Response Capability:  20Hz to 200kHz - AC input:  Universal Full-Range 85 to 265VAC 47 to 63Hz - AC Surge protection:  3 Varistor 285V, gas discharger and fuse

Power Supply Efficiency:  85% or better in 220V AC - Switching frequency:  100kHz - Input Connectors:  XLR Female

Internal Jumper selection for:  50 or 75us stereo pre-emphasis - Input Impedance:  600 Ohms unbalanced - Frequency Response:  20Hz to 15kHz (THD+N < 0,1%) - Input Level:  0dB for 75KHz carrier deviation - Stereo Separation:  Better than 45dB @ 1kHz - Pilot Tone Frequency/Stability: 19kHz +/- 1Hz - MPX Input: Input Impedance: 10k Ohms Unbalanced BNC Connector - Frequency Response: 20Hz to 200KHz +/- 1dB for 75kHz deviation -  Maximum humidity:  95% at +45ºC without condensation -*Specification subject to change without notice - Dimensions: 483mm (6”) wide, 44,45mm (1,5”) high, 150mm (4”) deep - Weight: 3,25 kgs

Prix HT:  925, 00  € Prix TVA: 1110, 00 €

BROADCAST EX 60W  FM EXITER
Frequency Range: .
87.5 ÷ 108 MHz  -Modulation:. FM
Type de modulation: . F3 - Harmonic and Spurious Attenuation:  >80dBc - Residual AM modulation (Assyncr.)  Approximately 0,05% (55dB) - Residual AM modulation (Syncr.)  Approximately 0,1% (65dB) - Intermodulation Distortion:  <0,05% @ 1kHz -Frequency Response Capability:  20Hz to 200kHz - AC input:  Universal Full-Range 85 to 265VAC 47 to 63Hz - AC Surge protection:  3 Varistor 285V, gas discharger and fuse

Power Supply Efficiency:  85% or better in 220V AC - Switching frequency:  100kHz - Input Connectors:  XLR Female

Internal Jumper selection for:  50 or 75us stereo pre-emphasis - Input Impedance:  600 Ohms unbalanced - Frequency Response:  20Hz to 15kHz (THD+N < 0,1%) - Input Level:  0dB for 75KHz carrier deviation - Stereo Separation:  Better than 45dB @ 1kHz - Pilot Tone Frequency/Stability: 19kHz +/- 1Hz - MPX Input: Input Impedance: 10k Ohms Unbalanced BNC Connector - Frequency Response: 20Hz to 200KHz +/- 1dB for 75kHz deviation -  Maximum humidity:  95% at +45ºC without condensation - *Specification subject to change without notice - Dimensions: 483mm (6”) wide, 44,45mm (1,5”) high, 150mm (4”) deep - Weight: 3,25 kgs

Survolez l’image pour l’agrandir

Prix HT:  1320, 00  € Prix TVA: 1584, 00 €

BROADCAST EX 150W  FM EXITER
Frequency Range: .
87.5 ÷ 108 MHz  -Modulation:. FM
Type de modulation: . F3 - Harmonic and Spurious Attenuation:  >80dBc - Residual AM modulation (Assyncr.)  Approximately 0,05% (55dB) - Residual AM modulation (Syncr.)  Approximately 0,1% (65dB) - Intermodulation Distortion:  <0,05% @ 1kHz -Frequency Response Capability:  20Hz to 200kHz - AC input:  Universal Full-Range 85 to 265VAC 47 to 63Hz - AC Surge protection:  3 Varistor 285V, gas discharger and fuse

Power Supply Efficiency:  85% or better in 220V AC - Switching frequency:  100kHz - Input Connectors:  XLR Female

Internal Jumper selection for:  50 or 75us stereo pre-emphasis - Input Impedance:  600 Ohms unbalanced - Frequency Response:  20Hz to 15kHz (THD+N < 0,1%) - Input Level:  0dB for 75KHz carrier deviation - Stereo Separation:  Better than 45dB @ 1kHz - Pilot Tone Frequency/Stability: 19kHz +/- 1Hz - MPX Input: Input Impedance: 10k Ohms Unbalanced BNC Connector - Frequency Response: 20Hz to 200KHz +/- 1dB for 75kHz deviation - Maximum humidity:  95% at +45ºC without condensation - *Specification subject to change without notice - Dimensions: 483mm (6”) wide, 88,90mm (2 RU) high, 355mm (14”) deep  - Weight: 12,5 kgs

Prix HT:  2380, 00  € Prix TVA: 2856, 00 €

BROADCAST EX 300W  FM EXITER
Frequency Range: .
87.5 ÷ 108 MHz  -Modulation:. FM
Type de modulation: . F3 - Harmonic and Spurious Attenuation:  >80dBc - Residual AM modulation (Assyncr.)  Approximately 0,05% (55dB) - Residual AM modulation (Syncr.)  Approximately 0,1% (65dB) - Intermodulation Distortion:  <0,05% @ 1kHz -Frequency Response Capability:  20Hz to 200kHz - AC input:  Universal Full-Range 85 to 265VAC 47 to 63Hz - AC Surge protection:  3 Varistor 285V, gas discharger and fuse

Power Supply Efficiency:  85% or better in 220V AC - Switching frequency:  100kHz - Input Connectors:  XLR Female

Internal Jumper selection for:  50 or 75us stereo pre-emphasis - Input Impedance:  600 Ohms unbalanced - Frequency Response:  20Hz to 15kHz (THD+N < 0,1%) - Input Level:  0dB for 75KHz carrier deviation - Stereo Separation:  Better than 45dB @ 1kHz - Pilot Tone Frequency/Stability: 19kHz +/- 1Hz - MPX Input: Input Impedance: 10k Ohms Unbalanced BNC Connector - Frequency Response: 20Hz to 200KHz +/- 1dB for 75kHz deviation - Maximum humidity:  95% at +45ºC without condensation - *Specification subject to change without notice - Dimensions: 483mm (6”) wide, 88,90mm (2 RU) high, 355mm (14”) deep  - Weight: 14,4 kgs

Prix HT:  2580, 00  € Prix TVA: 3096, 00 €

BROADCAST ETG 500W-5 FM EXITER
Frequency Range: .
87.5 ÷ 108 MHz  -Modulation:. FM - GENERAL DATA : RS232/RS485 Oui
RF PERFORMANCE : Output impedance 50 Ω - Automatic power RF control Stabilizes the output power value on the set value - Overall output power RF stability +/-0,1 dB - VSWR 2:1 on full power - automatic power reduction beyond 1.5:1 - transmitter is protected for short and open circuit - Harmonics < -75 dBc - Out of band emission (spurious) < -80dBc - CONNECTORS : RF Output connector N or 7/16 - MPX Connector BNC Female - LEFT & RIGHT Connectors XLR Female - AES/EBU Connector XLR Female -AUX Connectors BNC Female - Monitor/19kHz Connector BNC Female - MPX/STEREO CODER PERFORMANCE : AES/EBU Input Resolution 24bits - AES/EBU Input Sample Rate 32,44.1,48,96 KHz Automatically selected L/R Audio input level +15/-10 dBu for 75KHz standard deviation - L/R level adjustment Soft adjust 0.1dB steps from front panel L/R Input Impedance Selectable 10K - 600 Ω, balanced (for analog) 110 Ω (for digital) MPX audio input level +15/-10 dBu for 75KHz standard deviation MPX level adjustment Soft adjust 0.1 dBs  steps from front panel - L/R Input Impedance Selectable 10K - 600 Ω, balanced (for analog)

110 Ω (for digital) - MPX audio input level +15/-10 dBu for 75KHz standard deviation - Dimensions: W - H - D 48.5 - 8.5 - 58.5 cm 2U - Weight: 9,4 kgs

Prix HT:  3950, 00  € Prix TVA: 4740, 00 €
